ADAM Audio - SUB10 MKII

Artnr: IDS0014425
Tarneaeg: 2-7 tööpäeva.

Teave:

5 YEARS WARRANTY

Please register your product in the MyADAM user area after your purchase (the date on the purchase receipt applies) to receive an extended warranty totaling five years from the date of your purchase.

The regulations in your region relevant to product warranties apply. When you buy an ADAM Audio product, you receive the standard warranty period of two years. On registering your product in the MyADAM customer area of our website, the warranty is extended by three years to a total of five years. Should warranty extensions be illegal in your region, we cannot extend the warranty period.

WARRANTY TERMS:

https://www.adam-audio.com/en/warranty-terms/
ADAM Audio PRODUCT REGISTRATION:

https://www.adam-audio.com/en/my-adam/
How to extend your warranty up to 5 years
The Sub10 MK2 is a powerful subwoofer designed to extend the low frequency capabilities of any near or midfield monitoring system down to 25Hz.
A sturdy special woofer with extended cone travel and a heavy-duty coil have been optimized for accurate reproduction from a bass reflex enclosure. The down-firing bass reflex tube avoids intrusive ventilation noise because of its generous size and shape. The PWM amplifier produces over 90% efficiency and can handle critical passages without overheating for long periods of time. An additional output allows you to cascade as many subwoofers as needed.

The Sub10 MK2 subwoofer provides a precise combination of low cutoff frequency (-3 dB at 25Hz) and an undistorted high sound pressure level (113dB at 1m).

10“ Subwoofer (paper)
Amp. Power RMS / Music: 200 W / 300
Frequency response: 25 Hz - 150 Hz
Max. peak SPL at 1 m: ≥113 db

Features

Linear bass reproduction down to 25 Hz

Ideal addition to nearfield and midfield monitors
Maximum Peak sound pressure in 1 m ≥ 113 dB

Powerful, compression-free sound reproduction even at very high sound levels
High efficiency PWM amplifier

Low-distortion amplification at both low and high volume levels
Special 10" woofer with paper diaphragm

Unrestricted bass reproduction for low-fatigue operation even at high volumes
Easy manual or automatic (de-)activation

If desired, monitoring is possible without the low frequencies
According to downward working bass reflex tube with generous dimensions and corresponding rounding

Prevention of air turbulence noise
Upper cut-off frequency is selectable between 50 - 150 Hz

Allows optimal adaptation of the total system on the bass performance of the satellites
Connectable high-pass filter for the satellite outputs, which blocks signals below 85 Hz

Dolby®- Fair reproduction of film sound
Discharging the satellites from the low frequencies
2 years warranty with optional extension to 3 years with the registration of the product

Full repair service if required for 5 years

Specsifications:

Number: 1
Basket Ø: 10" (260 mm)
Voice Coil Ø: 2" (50 mm)
Cone Material: Paper

Built-In Amplifiers

Subwoofer: 1
Type: PWM
Amp. Power RMS / Music: 200 W / 300 W

Input Connectors

Analog: XLR / RCA

General Data

Frequency Response: 25 Hz - 150 Hz
THD > 60 Hz: ≤1 %
Max. peak SPL at 1 m: ≥113 dB
Crossover Frequencies: 50 - 150 Hz
Input Impedance: 10 kOhm
Panel: Rear
Weight: 46.3 lb (21 kg)
Height x Width x Depth: 22" (560 mm) x 12" (300 mm) x 15.5" (400 mm)
Warranty: 5 years (2 years warranty plus 3 years optional with product registration)
Delivery Contents: Power cord, manual

Package includes:

ADAM Audio Sub10 Mk2 subwoofer x1
Power cord x1
